Maximum scanning depth*

• Magnetic metal：12 cm

• Non-ferrous metal (copper)：10 cm

• Live wire：5 cm

• Copper wire (≥4 mm2)：4 cm

Operating humidity range:

• Metal mode：0-85%RH

• Ac mode：0-30%RH

Laser ranging parameter

Accuracy of measurement

+ / - 5 mm * *

unit

m

Measuring range (no reflector)

0.05-40 m * * *

Measuring time

0.3 -4 seconds

Laser type

Wavelength: 620~670nm, optical power <1mw

Self-closing laser

20 seconds

Store the data

30 sets of data

General   parameters

Automatic shutdown time

About 5 minutes

The screen

1.8 inch color screen

Battery type and life

600mAH built-in lithium battery, about 5000 times of   single measurement

Product size

135*60*25mm

Operating temperature range

0 C°～40 C°

Storage temperature range

-20 C°～60 C°
