Temperature measurement range

Can be measured to-20℃~+1000℃

Accuracy

±3Kor±3%,Use the maximum value(This accuracy   applies only to ambient temperature 15-50℃，The temperature of the object being measured 15-200℃)

Emissivity

default 0.95（0.01-1 adjustable）

Background reflection temperature compensation

Yes

Radiation coefficients adjust.

Yes

Imaging   performance

Response time

250ms

Thermal sensitivity

200mk

Frame frequency

≤6Hz

Infrared frequency range

8μm-14μm

Visible lens

300000 pixels

Focusing way

fixed

Infrared image resolution

1024 pixels （32x32）

Viewing Angle

33°

Graph   presentation

Color palette

Iron red, rainbow, gray

Infrared visible light fusion

0%(full thermal imaging)，25%，50%，75%，100%（All the visible light）。

Display   type

2.4”TFT LCD

Display resolution

240*320 pixels

Image   capture and data storage

Image capture

Freeze images to allow viewing before saving

storage medium

It has a built-in memory of 8M (7.8m can be used,   and can store 52 photos), supports the expansion of 32G Micro SD memory card   at most, and only supports SD card in FAT32 file format.

Image format

.bmp

View stored images

Press the button to turn the page on the screen and   display all saved images.

General   parameters

Battery

3*1.5V AAA or 1PC 18650 battery

Instrument current and voltage

Current :About 160mA，voltage :3.6~4.2V

Overall dimensions

210*101*60mm

Instrument net weight

220g (no batteries)

Operating temperature and humidity

-10~40℃    ＜85%RH

Storage temperature and humidity

-20~75℃    ＜85%RH
